April Beacon

Introduction

AprilBeacon is one of the most commonly used beacons. Supporting both iBeacon and Eddystone. Battery level can be shown in the advertising data or via a BLE connection.

While this beacon has both iOS and Android configuration apps, the iOS app is easier to use and is more functional. If you are setting up Eddystone-URL (for Android notifications) and you consider yourself to be non-technical then you will need use of an iOS device for setup.

Features

  • Configurable including UUID, major, minor and TX power etc
  • Upgrade Over-The-Air supported.

Models

April Beacon N02

  • Power supply by Lithium Battery 800 mAh
  • Dimension: 86mm * 54mm * 4mm
  • One LED and one button
  • BLE micro controller NRF52810

Button status

For Firmware version >= v4.0.6

  • Long push button 2 seconds and more
    • Turn on/off advertising
    • Stop advertising if fast blink
    • Start advertising if slow blink
  • Short press button
    • blink once
    • Advertise the 2nd UUID 30 seconds, then advertise the 1st UUID. (Default settings)

April Beacon N06

  • Power supply by CR2032 Battery 225~ mAh (replaceable).
  • Dimensions: 60mm x 35mm x 12mm
  • One LED and one button
  • BLE micro controller NRF52810 or NRF52820

ABSensor N07

N07 is a BLE beacon with temperature and humidity sensor. It advertises the temperature/humidity data with BTHome protocol.

BTHome is an open standard protocol for broadcasting sensor data. It is supported by popular home automation platforms, like Home Assistant, out of the box.

  • Nordic solution, long battery life. The BLE chip is NRF52820
  • Temperature and humidity sensor for environment monitoring
  • Power supply by CR2450 Battery 500~ mAh (replaceable).
  • Dimensions: 40mm x 40mm x 13.5mm
  • One LED and one button
